TECNOIOT INA226 IIC I2C Interface Bidirectional Current/Power Monitoring Sensor Pack of 2

TECNOIOT INA226 IIC I2C Interface Bidirectional Current/Power Monitoring Sensor Pack of 2

x2pcs INA226 IIC I2C Interface Bi-Directional Current/Power Monitoring Sensor Module The INA226 is a current shunt and power monitor with an I2C or SMBUS- compatible interface. Thedevice monitors both a shunt voltage drop and bussupply voltage. Programmable calibration value,conversion times, and averaging, combined with aninternal multiplier, enable direct readouts of current inamperes and power in watts. The INA226 senses current on common-mode bus voltages that can vary from 0 V to 36 V, independent of the supply voltage. The device operates from a single 2.7-V to 5.5-V supply, drawing a typical of 330μA of supply current. The device is specified over the operating temperature range between -40°C and 125°C and features up to 16 programmable addresses on the I2C-compatible interface. Specifications: Senses Bus Voltages From 0 V to 36 V High-Side or Low-Side Sensing Reports Current, Voltage, and Power High Accuracy: 0.1% gain error (max). 10 μV offset (max). Configurable Averaging Options 16 programmable addresses. Operates from 2.7-V to 5.5-V Power Supply 10-pin, DGS (VSSOP) Package Pin description: VBUS: bus voltage input. SDA/SCL: IIC bus data and clock signal lines ALERT: Multi-function alarm output A0/A1: IIC address line. IN+/IN-: non-inverting analogue input, inverting analogue input. Package contains: 2pcs x INA226 Current/Power Monitoring Sensor Module

Product Features

• INA226: The INA226 is a power shunt and performance monitor with an I2C or SMBUS compatible interface. The device monitors both a shunt voltage drop and the bus supply voltage. Programmable calibration values, conversion times and averaging combined with an internal multiplier allow direct display of current in amps and power in watts.
• CompatibleThe INA226 captures the current of common mode bus voltages, which can vary between 0V and 36V regardless of the supply voltage. The device is powered by a single 2.7V to 5.5V supply and typically consumes 330A of supply current. The device is specified for the operating temperature range between -40C and 125C and has up to 16 programmable addresses on the I2C compatible interface.
• Compact DesignDetects bus voltages from 0V to 36V; high-side or low-side detection; reports current, voltage and power. Configurable averaging options - 16 programmable addresses; operates from 2.7V to 5.5V power supply; 10-pin DGS (VSSOP) chassis
• High performance: high accuracy: 0.1% gain error (max. ); - 10 V offset (max. );
