1. 2 interface for 5V servo, connected to the high resolution dedicated timer - no jitter. 2. Can drive 4 DC motors or 2 stepper motors or 2 servos. 3. Up to 4 bi-directional DC motors with individual 8-bit speed selection. 4. Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil or interleaved stepping. 5. 4 H bridges: each bridge delivers 0.6A (1.2A peak current) with overheating protection. Specification: L293D is a monolithic integrated high voltage/high current 4-channel driver. Basically, this means that with this chip you can use DC motors and power supplies up to 36 volts, which are quite large motors, and the chip can provide a maximum current of 600mA per channel. The L293D chip is also a kind of H bridge. The H bridge is typically an electrical circuit that allows a voltage to be applied to an output via a load in both directions, e.g. motor. Features: 2 interfaces for 5V servo, connected to the high resolution dedicated timer - no jitter. Can drive 4 DC motors or 2 stepper motors or 2 servos. Up to 4 bi-directional DC motors with individual 8-bit speed selection. Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil or interleaved stepping. 4 H bridges: per bridge provides 0.6A (1.2A peak current) with overheating protection. Pull down resistors keep the motors off during power on. Built-in reset button. 2 external power connections, separate logic/motor supply. Specification: Motor voltage: 4.5V-25V. Current: ≤ 1 A. PCB size: 6.7 x 5.3 cm / 2.64 x 2.09 inches. Package list: 1 x motor drive shield expansion board.
Product Features
- L293D motor driver shielding for 2 interface for 5V servo, connected to the high resolution dedicated timer - no jitter.
- Motor Shield can drive 4 DC motors or 2 stepper motors or 2 servos.
- L293D motor driver shield for up to 4 bi-directional DC motors with individual 8-bit speed selection.
- Motor Drive Shield Board Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil or interleaved stepping.
- 4H bridges: per bridge delivers 0.6A (1.2A peak current) with thermal protection.
