Mean Well HDR-30-24 DIN Rail Power Supply DIN-Rail 24 VDC 1.5 A 36 Watt Single

Mean Well HDR-30-24 DIN Rail Power Supply DIN-Rail 24 VDC 1.5 A 36 Watt

Single-phase MEANWELL switching power supply series HDR-30, primarily clocked for DIN rail mounting in plastic housing. Can be mounted directly on the DIN rail. Closed design, touch-protected screw connections. Universal input. Overload protection thanks to current limitation, auto recovery. Protected against short circuit, overload, overvoltage. Compact size: 2 TE (DIN EN43880). Low idle power of only 0.3 watts. LED indicator for power-on Type: Clocked. Technology: constant voltage Mounting type: DIN rail power supply. Model: HDR Series No-load power: 0.3 watts. Power On/Off: LED indicator Operating temperature range: -30°C to +70°C. Voltage input AC: 85 - 264 V AC. Voltage input DC: 120 - 370 V DC. Mains frequency: 50/60Hz Voltage: output voltage | 24 VDC. Adjustable voltage: adjustable | from 21.6 V to 29 VDC. Current: output current: 1.5 A/1500 mA. Power: output power | 36 watts Efficiency: 89%. Inrush current: 45 A. Dimmable: no. Overload protection: yes. Overload protection in %: 105 - 160%. Surge Protection: Yes Short circuit resistant: yes. Temperature monitoring: yes. Insulation class: II. Insulation voltage: 3000V AC. Protection class: IP42. Installation area: indoor Colour: anthracite. Material: plastic. Length: 90 mm. Width: 35 mm / 2TE Height: 58.4 mm. Power connection: screw terminals. Output connection: screw terminals. Manufacturer: Mean Well. Manufacturer number: HDR-30-24. Package weight: 120 g. Certification: TÜV, CE, CB, UL, LPS. RoHS: compliant

Product Features

• Output voltage: 24 VDC
• Output current: 1.5 A / 1500 mA
• Output power: 36 watts
• Constant Voltage
• Adjustable | from 21.6 V to 29 VDC
