Hailege 5pcs HY-SRF05 Ultrasonic Sensor Module DC 5V HY-SRF05 Rangefinder Sensor Raspberry Pi
Hailege 5pcs HY-SRF05 Ultrasonic Sensor Module DC 5V HY-SRF05 Rangefinder Sensor Raspberry Pi
Hailege 5pcs HY-SRF05 Ultrasonic Sensor Module DC 5V HY-SRF05 Rangefinder Sensor Raspberry Pi
Specification: Working voltage: 5V DC Static current: less than 2mA. Output signal: electric frequency signal, high level 5V, low level 0V. Sensor angle: no more than 15 degrees. Detection distance: 2 cm - 450 cm. High Precision: Up to 0.12 inch Work seductor: -20C___ + 60C Weight:10g Size:45 x 21mm (L x W) Connecting pin: VCC Trig (T) Echo (R) OUT GND Package Content: 5 x HY-SRF05 ultrasonic distance sensor. 1 x Dupont cable set
Product Features
- Detection distance: 2 cm - 450 cm; compatible with electronic building blocks; breadboard friendly; dual converter; library ready.
- High quality HY-SRF05 ultrasonic sensor
- Output signal: electric frequency signal, high level 5V, low level 0V. Sensor angle: no more than 15 degrees.
- Operating voltage: 5V (DC); Static current: less than 2 mA.
- We offer the declaration of conformity. This product also includes an electronic user manual available in English, German, French, Spanish, Italian, Polish and Dutch. If you need support, please contact us.
More Images
Hailege 5pcs HY-SRF05 Ultrasonic Sensor Module DC 5V HY-SRF05 Rangefinder Sensor Raspberry Pi
Hailege 5pcs HY-SRF05 Ultrasonic Sensor Module DC 5V HY-SRF05 Rangefinder Sensor Raspberry Pi
Specification: Working voltage: 5V DC Static current: less than 2mA. Output signal: electric frequency signal, high level 5V, low level 0V. Sensor angle: no more than 15 degrees. Detection distance: 2 cm - 450 cm. High Precision: Up to 0.12 inch Work seductor: -20C___ + 60C Weight:10g Size:45 x 21mm (L x W) Connecting pin: VCC Trig (T) Echo (R) OUT GND Package Content: 5 x HY-SRF05 ultrasonic distance sensor. 1 x Dupont cable set
Product Features
- Detection distance: 2 cm - 450 cm; compatible with electronic building blocks; breadboard friendly; dual converter; library ready.
- High quality HY-SRF05 ultrasonic sensor
- Output signal: electric frequency signal, high level 5V, low level 0V. Sensor angle: no more than 15 degrees.
- Operating voltage: 5V (DC); Static current: less than 2 mA.
- We offer the declaration of conformity. This product also includes an electronic user manual available in English, German, French, Spanish, Italian, Polish and Dutch. If you need support, please contact us.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Hailege 5pcs HY-SRF05 Ultrasonic Sensor Module DC 5V HY-SRF05 Rangefinder Sensor Raspberry Pi
Specification: Working voltage: 5V DC Static current: less than 2mA. Output signal: electric frequency signal, high level 5V, low level 0V. Sensor angle: no more than 15 degrees. Detection distance: 2 cm - 450 cm. High Precision: Up to 0.12 inch Work seductor: -20C___ + 60C Weight:10g Size:45 x 21mm (L x W) Connecting pin: VCC Trig (T) Echo (R) OUT GND Package Content: 5 x HY-SRF05 ultrasonic distance sensor. 1 x Dupont cable set
Product Features
- Detection distance: 2 cm - 450 cm; compatible with electronic building blocks; breadboard friendly; dual converter; library ready.
- High quality HY-SRF05 ultrasonic sensor
- Output signal: electric frequency signal, high level 5V, low level 0V. Sensor angle: no more than 15 degrees.
- Operating voltage: 5V (DC); Static current: less than 2 mA.
- We offer the declaration of conformity. This product also includes an electronic user manual available in English, German, French, Spanish, Italian, Polish and Dutch. If you need support, please contact us.
