Hailege 4pcs NRF24L01+ 2.4G Wireless Transceiver Module Wireless Transceiver Radio Transceiver Module RF PI ARM Wireless Model 200M
Hailege 4pcs NRF24L01+ 2.4G Wireless Transceiver Module Wireless Transceiver Radio Transceiver Module RF PI ARM Wireless Model 200M
Hailege 4pcs NRF24L01+ 2.4G Wireless Transceiver Module Wireless Transceiver Radio Transceiver Module RF PI ARM Wireless Model 200M
Description: NRF24L01 is a monolithic transceiver chip used worldwide in the 2.4-2.5GHz ISM band, a wireless transceiver consisting of: frequency generator, mode controller, enhanced shockburstTM amplifier, transistor amplifier, output power modulator, demodulator, channel selection and protocol settings can be very low via the SPI interface set The transmission power in transmission mode is 9.0 mA with low power consumption, the accepted mode 6 dBm for the next power off mode and the standby mode 12.3 mA power consumption pattern. Six channels support data reception: 1. Low operating voltage: 1.9 to 3.6 V low voltage operation 2. High rate: 2 Mbps because the air transmission time is very short, greatly reducing collisions in wireless transmission (air transfer rate can be adjusted to 1 Mbps or 2 Mbps by software) 3. Multi- frequency: 125 frequency points, multi-point communication and frequency hopping method to meet communication requirements. 4. Ultra-small size: Built- in 2.4GHz antenna, compact, 15 x 29 mm (including antenna) 5. Low power consumption: When working in response mode of communication, air transport and fast start time, the power consumption is significantly reduced. Package includes: 4 x NRF24L01+ 2.4G wireless transceiver module
Product Features
- NRF24L01+ 2.4G Wireless Transceiver Module
- Multi-frequency: 125 frequency points
- Multi-point communication and frequency jump, can meet different communication requirements
- Low operating voltage: 1.9-3.6V low voltage operation
- We offer the declaration of conformity. This product also includes an electronic user manual available in English, German, French, Spanish, Italian, Polish and Dutch. If you need support, please contact us.
Original: $85.48
-65%$85.48
$29.92More Images
Hailege 4pcs NRF24L01+ 2.4G Wireless Transceiver Module Wireless Transceiver Radio Transceiver Module RF PI ARM Wireless Model 200M
Hailege 4pcs NRF24L01+ 2.4G Wireless Transceiver Module Wireless Transceiver Radio Transceiver Module RF PI ARM Wireless Model 200M
Description: NRF24L01 is a monolithic transceiver chip used worldwide in the 2.4-2.5GHz ISM band, a wireless transceiver consisting of: frequency generator, mode controller, enhanced shockburstTM amplifier, transistor amplifier, output power modulator, demodulator, channel selection and protocol settings can be very low via the SPI interface set The transmission power in transmission mode is 9.0 mA with low power consumption, the accepted mode 6 dBm for the next power off mode and the standby mode 12.3 mA power consumption pattern. Six channels support data reception: 1. Low operating voltage: 1.9 to 3.6 V low voltage operation 2. High rate: 2 Mbps because the air transmission time is very short, greatly reducing collisions in wireless transmission (air transfer rate can be adjusted to 1 Mbps or 2 Mbps by software) 3. Multi- frequency: 125 frequency points, multi-point communication and frequency hopping method to meet communication requirements. 4. Ultra-small size: Built- in 2.4GHz antenna, compact, 15 x 29 mm (including antenna) 5. Low power consumption: When working in response mode of communication, air transport and fast start time, the power consumption is significantly reduced. Package includes: 4 x NRF24L01+ 2.4G wireless transceiver module
Product Features
- NRF24L01+ 2.4G Wireless Transceiver Module
- Multi-frequency: 125 frequency points
- Multi-point communication and frequency jump, can meet different communication requirements
- Low operating voltage: 1.9-3.6V low voltage operation
- We offer the declaration of conformity. This product also includes an electronic user manual available in English, German, French, Spanish, Italian, Polish and Dutch. If you need support, please contact us.
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Hailege 4pcs NRF24L01+ 2.4G Wireless Transceiver Module Wireless Transceiver Radio Transceiver Module RF PI ARM Wireless Model 200M
Description: NRF24L01 is a monolithic transceiver chip used worldwide in the 2.4-2.5GHz ISM band, a wireless transceiver consisting of: frequency generator, mode controller, enhanced shockburstTM amplifier, transistor amplifier, output power modulator, demodulator, channel selection and protocol settings can be very low via the SPI interface set The transmission power in transmission mode is 9.0 mA with low power consumption, the accepted mode 6 dBm for the next power off mode and the standby mode 12.3 mA power consumption pattern. Six channels support data reception: 1. Low operating voltage: 1.9 to 3.6 V low voltage operation 2. High rate: 2 Mbps because the air transmission time is very short, greatly reducing collisions in wireless transmission (air transfer rate can be adjusted to 1 Mbps or 2 Mbps by software) 3. Multi- frequency: 125 frequency points, multi-point communication and frequency hopping method to meet communication requirements. 4. Ultra-small size: Built- in 2.4GHz antenna, compact, 15 x 29 mm (including antenna) 5. Low power consumption: When working in response mode of communication, air transport and fast start time, the power consumption is significantly reduced. Package includes: 4 x NRF24L01+ 2.4G wireless transceiver module
Product Features
- NRF24L01+ 2.4G Wireless Transceiver Module
- Multi-frequency: 125 frequency points
- Multi-point communication and frequency jump, can meet different communication requirements
- Low operating voltage: 1.9-3.6V low voltage operation
- We offer the declaration of conformity. This product also includes an electronic user manual available in English, German, French, Spanish, Italian, Polish and Dutch. If you need support, please contact us.
